Telit LE910 V2 Series AT Commands
80446ST10707A Rev. 0– 2015-11-03
Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 281 of 509
Mod. 0808 2011-07 Rev.2
and, after a while, a list of informations, one for each received carrier, is
reported, each of them in the format:
In 2G
(For BCCH-Carrier)
arfcn
: <arf
cn> bsi
c: <bs
ic> rx
Lev: <rx
Lev
> ber: <be
r> m
cc: <m
cc> mnc
:
<mnc> lac: <lac> cellId: <cellId> cellStatus: <cellStatus> numArfcn:
<numArfcn> arfcn: [<a
rfcn1> ..[ <arfcn64>]] [numChannels:
<numChannels> array: [<ba1> ..[<ba32>]] [pbcch: <pbcch> [nom:
<nom
> rac: <r
ac> spg
c:
<spgc> p
at: <pa
t> nco
: <nco
> t3168
: <t31
68>
t3192: <t3192> drxmax: <drxmax> ctrlAck: <ctrlAck> bsCVmax:
<bsCVmax> alpha: <alpha> pcMeasCh: <pcMeasCh>]]] mstxpwr:
<mstxpwr> rxaccmin: <rxaccmin> croffset: <croffset> penaltyt:
<penaltyt> t3212: <t3212> CRH: <CRH>
<CR><LF><CR><LF><CR><LF>
where:
- the cell carrier assigned radio channel (BCCH - Broadcast
Control Channel)
- base station identification code; if
last setting is 0,
is a decimal number, else it is
a 2-digits octal
number
- decimal number; it is the receiption level (in dBm)
- decimal number; it is the bit error rate (in %)
- hexadecimal 3-digits number; it is the mobile country code
- hexadecimal 2-digits number; it is the mobile network code
- location area code; if
last setting is 0,
is a decimal
number, else it is a 4-digits hexadecimal number
- cell identifier; if
last setting is 0,
is a decimal
number, else it is a 4-digits hexadecimal number
- string type; it is the cell status
..CELL_SUITABLE - the cell is a suitable cell.
CELL_LOW_PRIORITY - the cell is low priority based on the received
system information.
CELL_FORBIDDEN - the cell is forbidden.
CELL_BARRED - the cell is barred based on the received system
information.
CELL_LOW_LEVEL - the cell <rxLev> is low.
