YASKAWA NX100 User Manual

3 Teaching
3.9 Other Job-editing Functions
3-86
149235-1CD
RE-CSO-A031
 Instruction Search
This function moves the cursor to a desired instruction.
Operation Explanation
1 Select {EDIT}, {SEARCH} and
“INSTRUCTION SEARCH.”
The INFORM command list appears.
2 Select desired instruction
group.
3 Select desired instruction. The instruction is searched out and the cursor is on its line
number.
4 Use the cursor to continue
searching.
It is possible to continue searching by pressing the cursor key.
To end searching, select {EDIT}  {END SEARCH} on the menu
and press [SELECT] or press [CANCEL].
Short CutMain Menu
JOB CONTENT
JOB NAME : TEST01
CONTROL GROUP : R1
0000
0001
0002
0003
0004
0005
0006
0007
NOP
’This job is test job
MOVJ VJ=50.00
MOVJ VJ=12.50
MOVL V=276
TIMER T=1.00
DOUT OT#(1) ON
MOVL V=138
TOOL : 00
STEP NO.: 0003
JOB
EDIT
DISPLAY
UTILITY
IN/OUT
CONTROL
DEVICE
MOTION
ARITH
SHIFT
OTHER
Short Cut
Main Menu
ARCON ASF#(1)
JOB CONTENT
JOB NAME : TEST01
CONTROL GROUP : R1
0010
0011
0012
0013
0014
0015
0016
0017
ARCON ASF#(1)
MOVJ VJ=100.00
TIMER T=1.00
MOVL V=138
MOVL V=138
MOVJ VJ=50.00
MOVJ VJ=100.00
DOUT OT#(1) ON
TOOL : 00
STEP NO. : 0003
JOB
EDIT DISPLAY
UTILITY
Short CutMain Menu
JOB CONTENT
JOB NAME
TEST01
CONTROL GROUP
R1
0010
0011
0012
0013
0014
0015
0016
0017
ARCON ASF#(1)
MOVJ VJ=100.00
TIMER T=1.00
MOVL V=138
MOVL V=138
MOVJ VJ=50.00
MOVJ VJ=100.00
DOUT OT#(1) ON
TOOL : 00
STEP NO.
0003
JOB EDIT DISPLAY
UTILITY
TOP LINE
END LINE
END SEARCH
ENABLE SPEED TAG
ENABLE POS LVL TAG
150 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
