YASKAWA NX100 User Manual

4 Playback
4.1 Preparation for Playback
4-1
149235-1CD
RE-CSO-A031
4 Playback
4.1 Preparation for Playback
4.1.1 Selecting a Job
Playback is the act of executing a taught job. Before playback operation, first call the job to be
executed.
 Calling a Job
Operation Explanation
1 Select {JOB} under the main
menu.
2 Select {SELECT JOB}. The JOB LIST window appears.
3 Select the desired job.
Main Menu Short Cut
JOB LIST
TEST03
TEST
TEST3A
TEST01
TEST3A-!
TEST02
JOB EDIT
DISPLAY
UTILITY
153 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
