YASKAWA NX100 User Manual

9 Arc Welding Application
9.14 Table of Work Instructions
9-109
149235-1CD
RE-CSO-A031
9.14 Table of Work Instructions
• < > indicates alpha-numerical data.
• If multiple items are shown in one additional item section, select one.
Arc Welding Instructions
ARCON
Function
Outputs arc start conditions and an arc start instruction for the
Power Source.
Additional
Item
WELD1, WELD2, WELD3, WELD4 Displayed only
when using
multiple
manipulators.
AC = <welding current >
ASF#(<arc start condition file number>)
AC: 1 to 999A
ASF#(): 1 to
396
AV = <welding voltage >
AVP = <percentage against proper welding
voltage>
AV:
independent
0.1 to 50.0V
AVP: synergic
50 to 150%
T = <manipulator stopping time> 0.01 to 655.35
sec
V = <manipulator moving speed> 0.1 to 1500.0
mm/sec
1 to 9000 cm/
min
RETRY Specifies use of
arc retry
function.
Example
ARCON AC=200 AVP=100 T=0.30 RETRY
ARCON AC=200 AV=22.0 T=0.30
ARCON ASF#(1)
ARCON
452 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
