1 Introduction
1.2 Programming Pendant
1-3
149235-1CD
RE-CSO-A031
1.2.2 Key Description
 Character Keys
The keys which have characters printed on them are denoted with [ ]. For example, is shown as
[ENTER].
The Numeric keys have additional functions along with their number values. Dual function keys are
used in the context of the operation being performed. For example: may be described in the text
as [1] or [TIMER].
 Symbol Keys
The keys which have a symbol printed on them are not denoted with [ ] but depicted with a small
picture, with the exception of the cursor key, which is not shown with a picture.
 Axis Keys and Numeric Keys
The keys pictured in the following are referred to as the axis keys and Numeric keys when described.
 Keys Pressed Simultaneously
When two keys are to be pressed simultaneously, the keys are shown with a “+” sign between them,
such as [SHIFT]+[COORD].
Cursor
Emergency Stop button
Direct Open key
Page key
ENTER
1
TIMER
DIRECT
OPEN
PAGE
GO BACK
Axis K eys
Numeric Keys
Ｓ+
Ｘ-
L-
Y-
U-
Z-
Ｓ+
Ｘ+
L+
Y+
U+
Z+
R-
Ｘ-
B-
Y-
T-
Z-
R+
Ｘ+
B+
Y+
T+
Z+
･･
7 8 9
4 6
1 2 3
･
-
0
5
