YASKAWA NX100 User Manual

9 Arc Welding Application
9.5 Welding Condition Files
9-47
149235-1CD
RE-CSO-A031
9.5.4 Arc End Condition File
COND NO. (1 to 396)
Displays a condition number between 1 and 396.
COMM.
Displays a comment of 32 characters or less.
CURRENT (1 to 999A)
Welding current output value at the end of welding.
VOLTAGE (0 to 50.0V, 50 to 150%)
Welding voltage output value at the end of welding.
ROBOT PAUSE TIME (0 to 10.00 seconds)
The period during arc end when the manipulator is stopped.
ANTI-STICK
Specifies whether the automatic wire anti-stick function is used or not.
MONITORING(0 to 9.9 seconds)
Wire stick monitoring time at the end of welding.
WELDER CONTROL PRMTR (0000 to 9999, 10000: NOT USED)
At the beginning of welding, the value (0 to 9999) specified in the “WELDER CONTROL
PRMTR” is output to the following system register. At the end of welding, the same welder
control parameter can be specified, overwriting the same system register.
System register for each application “WELDER CONTROL PRMTR“
M468: device 1 (--> register for arc 1)
M478: device 2 (--> register for arc 2)
M488: device 3 (--> register for arc 3)
M498: device 4 (--> register for arc 4)
*Set the value to 10000 when “WELDER CONTROL PRMTR” is not used.
DATA
EDIT
DISPLAY
UTILITY
ARC END CONDITION
COND NO.: 1/396
COMM. weld1
CURRENT
VOLTAGE
ROBOT PAUSE TIME
ANTI-STICK
MONITORING
WELDER CONTROL PRMTR
: 120 A
: 80 %
: 0.01 sec
: OFF
: 0.2 sec
: NOT USED








390 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
