9 Arc Welding Application
9.4 Registering Arc Welding Instructions
9-30
149235-1CD
RE-CSO-A031
9.4.3 ARCSET
This is the instruction to set the welding conditions (current, voltage, etc.) individually.
The ARCSET instruction can be registered in any of the following two ways:
• With additional items to specify conditions
ARCSET AC=200 AVP=100
• With an arc start condition file
ARCSET ASF# (1)
In this case, the welding condition is set using the arc start condition file.
(Refer to section 9.5 "Welding Condition Files")
 Registering the ARCSET Instruction
With Additional Items to Specify Conditions
Operation Explanation
1 Move the cursor to the
address area.
2 Press [INFORM LIST]. The instruction list dialog box appears.
3 Select “DEVICE.”
4 Select the ARCSET
instruction.
The ARCSET instruction appears in the input buffer line.
IN/OUT
CONTROL
DEVICE
MOTION
ARITH
SHIFT
OTHER
SAME
PRIOR
ARCON
ARCOF
VWELD
AWELD
ARCSET
WVON
WVOF
ARCCTS
ARCCTE
JOB
EDIT
DISPLAY
UTILITY
Main Menu ShortCut
! Turn on servo power
JOB CONTENT1
ARCSET AC=200 AVP=100
JOB NAME: WORK A
0000 NOP
0001 MOVJ VJ=80.00
0002 MOVL V=800
0003 ARCON
0004 MOVL V=50
0005 END
TOOL: 00
CONTROL GROUP: R1
STEP NO: 0003
OTHER
SAME
PRIOR
ARCON
ARCOF
VWELD
AWELD
ARCSET
WVON
WVOF
ARCCTS
ARCCTE
IN/OUT
CONTROL
DEVICE
MOTION
ARITH
SHIFT
373 of 493
