7 External Memory Devices
7.3 Operation Flow
7-38
149235-1CD
RE-CSO-A031
Verifying Data
Follow the procedure below to verify data in the memory of the NX100 with data saved in the external
memory device.
Verifying a Job
This function cannot be executed with “BATCH USER MEMORY,” “BATCH CMOS,” or
“ALL CMOS AREA” specified.
Operation Explanation
1 Select {FD/PC CARD} under
the main menu.
2 Select {VERIFY}. The following window appears.
3 Select {JOB}. The job selection window appears.
NOTE
DATA UTILITY
EDIT
DISPLAY
Main Menu
ShortCut
FLOPPY DISK/Compact Flash
CF (VERIFY) UN-USED MEMORY 54.73 MB
FOLDER
JOB
FILE/GENERAL DATA
BATCH USER MEMORY
PARAMETER
SYSTEM DATA
I/O DATA
BATCH CMOS
ALL CMOS AREA
57
0
0
0
0
0
0
0
DATA
UTILITY
EDIT
DISPLAY
Main Menu ShortCut
FLOPPY DISK/Compact Flash
CF (VERIFY) SINGLE NO. 33
FOLDER
AA36
AA5
AA8
N1
TEST3
TEST3A-’
TEST3A--
TEST3A-3
TEST3A-6
TEST3A-9
TEST3A-C
AA37
AA6
AA9
TEST
TEST3A
TEST3A-(
TEST3A-1
TEST3A-4
TEST3A-7
TEST3A-A
TEST3A-D
AA35
AA4
AA7
N
TEST2
TEST3A-!
TEST3A-)
TEST3A-2
TEST3A-5
TEST3A-8
TEST3A-B
