YASKAWA NX100 User Manual

7 External Memory Devices
7.1 Memory Devices
7-2
149235-1CD
RE-CSO-A031
7.1.1 Compact Flash (CF Cards)
The programming pendant is equipped with CF card slot. Use the FAT16 or FAT32 formatted Compact
Flash.
 Recommended Compact Flash Cards
Recommended products used for external memory of NX100 are listed below. Model numbers are
subject to be updated due to termination of product and new addition. Contact Yaskawa representative
when necessary.
<Currently Recommended Compact Flash Cards>
<Previously Recommended Compact Flash Cards>
*512 MB (or more) CF cards in the same series can be used as external memory devices. However,
FAT32 formatted CF cards such as high-capacity CF cards cannot be used for upgrading Pendant OS
version.
No. Manufacturer Model Remarks
1
Hagiwara Sys-Com MCF10P-128MS
(A00A II -YE
(128MB)
2
Hagiwara Sys-Com MCF10P-256MS-YE2 (256MB)
3
Hagiwara Sys-Com MCF10P-512MS (512MB)
4
Hagiwara Sys-Com MCF10P-A01GS (1GB)
5
Hagiwara Sys-Com MCF10P-A02GS (2GB)
No. Manufacturer Model Remarks
1
Hagiwara Sys-Com CFI-128MDG (128MB)
2
Hagiwara Sys-Com CFI-256MDG (256MB)
3
Hagiwara Sys-Com CFC-064MBA
(HOOAA)
(64MB)
4
Hagiwara Sys-Com CFI-064MBA
(HOOAA)
(64MB)
5
SanDisk SDCFBI-64-EXPP-80 (64MB)
246 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
