YASKAWA NX100 User Manual

9 Arc Welding Application
9.13 Power Source Condition File Initial Value
9-97
149235-1CD
RE-CSO-A031
 Contents of 24 Welder Condition Files
The following tables give the original contents of the provided Power Source condition files, that are
associated with the Power Source numbers 1 through 24:
POWER SOURCE NO.: 1
POWER SOURCE NAME:
MOTOWELD-E series 350A class
COMMENT: COMBINATION GAS AND WIRE
POWER SUPPLY: A (synergic)
SHIELDING GAS: MAG
WIRE DIA.: 1.2 mm
WIRE STICKOUT: 15 mm
WIRE ANTI-STICKING: 0.1sec
ARC FAILURE STOP: 0.6 sec
POWER SOURCE NO.: 2
POWER SOURCE NAME:
MOTOWELD-E series 350A class
COMMENT: COMBINATION GAS AND WIRE
POWER SUPPLY: independent
SHIELDING GAS: MAG
WIRE DIA.: 1.2 mm
WIRE STICKOUT: 15 mm
WIRE ANTI-STICKING: 0.1 sec
ARC FAILURE STOP: 0.6 sec
CURRENT VOLTAGE CURRENT VOLTAGE
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
REF. (V) MEA. (A) REF. (V) MEA. (%) REF. (V) MEA. (A) REF. (V) MEA. (V)
0.00 30 0.00 50 0.00 30 0.00 12.0
1.35 62 7.20 99 1.35 62 2.25 16.0
2.70 94 7.50 100 2.70 94 4.50 20.0
10.80 286 7.80 101 10.80 286 6.75 24.0
12.15 318 14.00 150 12.15 318 9.00 28.0
13.50 350 0.00 0 13.50 350 11.25 32.0
0.00 0 0.00 0 0.00 0 13.50 36.0
0.00 0 0.00 0 0.00 0 0.00 0.0
440 of 493
