YASKAWA NX100 User Manual

10 Table of Basic Instructions
10.2 I/O Instructions
10-5
149235-1CD
RE-CSO-A031
10.2 I/O Instructions
DOUT
Function
Turns the external output signals ON and OFF.
Additional
Item
OT# (<output number>),
OGH# (<output group number>),
OG# (<output group number>)
Number of addressed output signals:
OT#(xx)=1;OGH#(xx)=4(per group);
OG#(xx)=8(per group)
OGH#(xx) is not subject to parity check; only the
binary specification is allowed.
FINE With a high
degree of
accuracy
Example
DOUT OT#(12) ON
PULSE
Function
Outputs a pulse signal as an external output signal.
Additional
Item
OT# (<output number>),
OGH# (<output group number>),
OG# (<output group number>)
T=<time (seconds)> 0.01 to
655.35 s
0.30 s unless
otherwise
specified
Example
PULSE OT# (10) T=0.60
460 of 493
