7 External Memory Devices

7.3 Operation Flow

7-11

149235-1CD

RE-CSO-A031

 Operating a Folder

Folders can be used in order to classify and sort out the data such as jobs and condition files when

using the Compact Flash. The folders can be created in hierarchical structure positioning a root folder

at the top.

Restrictions

Folder name: Up to 8 one-byte characters + 3 characters for extension

*Long folder names cannot be used such as the name that exceeds the restricted number of

characters mentioned above as created in PC, etc.

Maximum path length: 64 one-byte characters

*“ERROR 3360: INVALID FOLDER” appears when selecting the folder of which name exceeds the

maximum path length.

Selecting a Folder

Operation Explanation

1 Select {FD/PC CARD} under

the main menu.

2 Select {FOLDER}. The FOLDER LIST window appears.

3 Move the cursor to a folder

and press [SELECT].

A folder can be selected.

4 To move the hierarchy from a

child folder to a parent folder,

move the cursor to [..] and

press [SELECT].

FOLDER LIST

TARGET FOLDER FOLDER 1

FOLDER NUM.

0003

[ . . ] FOLDER 2 FOLDER 3

DATA UTILITY

EDIT

DISPLAY

Main Menu

ShortCut
