Page #137 background image
3 Teaching
3.9 Other Job-editing Functions
3-73
149235-1CD
RE-CSO-A031
Setting Position Variables Using the Axis Keys
Pulse Type
XYZ Type
Operation Explanation
1 Select {VARIABLE} under the
main menu.
2 Select desired position
variable type.
The desired variable window appears (robot, base, or station).
3 Press [SHIFT] + [ROBOT]. When you need an external axis position, press
[SHIFT]+[EX.AXIS].
When there are two or more robot, base, or a station, specify the
axis with following operation.
Robot
Each time [SHIFT] + [ROBOT] is pressed, the axis displayed on
the status line changes:
R1 R2 R3 R4.
Base or Station
Each time [SHIFT]+[EX.AXIS] is pressed, the axis displayed on
the status line changes:
B1 B2 B3 B4 S1 S2 S3  S12
4 Move the manipulator with the
axis keys.
Move the manipulator or the external axis to the desired position
to be set to position variable.
5 Press [MODIFY].
6 Press [ENTER].
Operation Explanation
1 Select {VARIABLE} under the
main menu.
2 Select desired position
variable type.
When there are two or more robot, base, or a station, specify the
axis with following operation.
Robot
Each time [SHIFT] + [ROBOT] is pressed, the axis displayed on
the status line changes:
R1 R2 R3 R4.
Base or Station
Each time [SHIFT]+[EX.AXIS] is pressed, the axis displayed on
the status line changes:
B1 B2 B3 B4 S1 S2 S3  S12
3 Move the manipulator with the
axis keys.
Move the manipulator or the external axis to the desired position
to be set to position variable.
4 Press [MODIFY].
5 Press [ENTER].
