YASKAWA NX100 User Manual

7 External Memory Devices
7.3 Operation Flow
7-10
149235-1CD
RE-CSO-A031
7.3 Operation Flow
The following description is the operation flow for external memory devices.
• SELECT DEVICE
Select {FD/PC CARD} --> {DEVICE}, and the destination device for saving.
The device selected is valid after turning the power supply ON again.
*1 Sub menu {FORMAT} appears when selecting FC1 or FC2.
• SELECT FOLDER
Select {FD/PC CARD} --> {DEVICE}, and the destination folder for saving.
The folder selected is invalid after turning the power supply ON again.
*2 {FOLDER} appears when using the Compact Flash as a device.
*3 The settings of {CREATE NEW FOLDER}, {DELETE FOLDER}, and {ROOT FOLDER} can be
set.
• SELECT SUB MENU
Select an operation to be performed from {LOAD}, {SAVE}, {VERIFY}, and {DELETE}.
• SELECT DATA CATEGORY
Select the target data category.
• SELECT DATA
Select the target data.
" BATCH USER MEMORY", " BATCH CMOS", and " ALL CMOS AREA" do not require this
operation.
*4 Individual selection, batch selection, marker (*) selection, and canceling selection can be
performed.
• EXECUTE
Select [ENTER] or {EXECUTE}.
Main Menu
{FD/PC CARD}
Sub Menu
{LOAD} {SAVE} {VERIFY} {DELETE} {FORMAT} {DEVICE} {FOLDER}
Select Data Category
Select Data
Select [ENTER] or {EXECUTE}
Select Floppy Type
Select Size
Select
Device
Operate Folder
{EXECUTE} Select Folder
*1 *2
*3
*4
254 of 493
