9 Arc Welding Application
9.12 Power Source Condition File
9-93
149235-1CD
RE-CSO-A031
Editing Other Items
Editing a Power Source Condition File for Current/Voltage Output
Editing the “RANGE”
Operation Explanation
1 Select the item to be edited.
2 Input the number using the
Numeric keys.
Operation Explanation
1 Select “RANGE.” Each time [SELECT] is pressed, the indication alternates
between “+” (positive) and “” (negative).
SETTING
POWER SOURCE NAME
COMM.
POWER SUPPLY
SHIELDING GAS
WIRE DIA.
WIRE STICKOUT
ANTI-STICKING
ARC FAILURE STOP
: DONE
: MOTOWELD-E350
: STC CONTROL NONE
: A/%
: CO2
: 0.1 mm
: 15 mm
: 0.1 sec
: 1.50 sec
<CURRENT OUTPUT CHAR.> <WELDING VOLTAGE OUTPUT CHAR.>
RANGE: + +
ADJUST: 1.00 1.00
<CURRENT OUTPUT CHAR.> <WELDING VOLTAGE OUTPUT CHAR.>
RANGE: +
ADJUST: 1.00 1.00
SELECT
