8 Parameter
8.8 Hardware Control Parameters
8-48
149235-1CD
RE-CSO-A031
S2C646 to S2C648: COOLING FAN ALARM DETECTION
This parameter specifies a detection for cooling fan 1 to 3 with alarm sensor, connected to power ON
unit.
0: No detection
1: Detected with message display
2: Detected with message and alarm display
S4C181 to S4C212: SETTING OF OPERATING RELAY NO.
Up to 32 output signals can be turned ON/OFF with the programming pendant. The object relay No. is
set in these parameters. Although it is possible to set optional values for output No. 1 to 1024 in the
parameters, the following must be taken into consideration.
• Avoid setting duplicate numbers.
• The signal turned ON or OFF with the programming pendant is operated again or remains
unchanged until the instruction is executed.
S4C213 to S4C244: OPERATING METHOD OF RELAYS
These parameters specify the operating method of output signals by the programming pendant. The
operating method can be specified for each output signal.
S2C649 to S2C651: COOLING FAN ALARM 1 OPERATION
S2C652 to S2C654: COOLING FAN ALARM 2 OPERATION
Parameter Setting
Value
Operation of Output Signal
0
1
+
ON
-
OFF
ON
OFF
+
ON
ON/OFF with the key
ON while the key
is pressed
OFF if the key is
not pressed
ON
OFF
