7 External Memory Devices
7.2 Handling Data
7-9
149235-1CD
RE-CSO-A031
7.2.3 File Existence
The following data categories show whether the same file name as a file that is going to be saved is in
the external memory device or not.
• JOB
No mark appears when the selected folder has the file of the same name.
The asterisk (*) appears when the folder does not have the same name file.
• FILE/GENERAL DATA, PARAMETER, SYSTEM DATA, I/O DATA
Black circle ( ) appears when the selected folder has the file of the same name.
White circle ( ) appears when the folder does not have the same name file.
Saving by Overwriting
“ BATCH USER MEMORY”, “ BATCH CMOS”, and “ ALL CMOS AREA” can be overwritten.
As for “ JOB”, “ FILE/GENERAL DATA”, “ PARAMETER”, “ SYSTEM DATA”, and
“ I/O DATA”, those data cannot be overwritten. Delete the target file in the device before the saving
operation. If Compact Flash is used as the device, the file does not need to be deleted because
another folder can be created to save the data.
Whether the job after editing is saved or not can be judged by checking “TO SAVE TO FD”
in the JOB HEADER window. However, the status of “TO SAVE TO FD” does not change
after saving “ BATCH USER MEMORY” and “ BATCH CMOS.”
Example of JOB Example of FILE/GENERAL DATA
DATA
UTILITY
EDIT
DISPLAY
Main Menu ShortCut
AA36
AA5
AA8
N1
TEST3
TEST3A-’
TEST3A--
TEST3A-3
TEST3A-6
TEST3A-9
TEST3A-C
AA35
AA4
AA7
N
TEST2
TEST3A-!
TEST3A-)
TEST3A-2
TEST3A-5
TEST3A-8
TEST3A-B
FLOPPY DISK/Compact Flash
CF (SAVE) SINGLE NO. 33
FOLDER
AA37
AA6
AA9
TEST
TEST3A
TEST3A-(
TEST3A-1
TEST3A-4
TEST3A-7
TEST3A-A
TEST3A-D
DATA UTILITY
EDIT
DISPLAY
Main Menu ShortCut
FLOPPY DISK/Compact Flash
CF(SAVE)
FOLDER
TOOL DATA
WEAVING DATA
USER COORDINATE DATA
VARIABLE DATA
ARC START COND DATA
ARC END COND DATA
ARC AUXILIARY COND DATA
POWER SOURCE COND DATA
USER DEF PWR SRC COND DATA
INTERRUPT JOB
TOOL
WEAV
UFRAME
VAR
ARCSRT
ARCEND
ARCSUP
WELDER
WELDUDEF
INTJOB
.CND
.CND
.CND
.DAT
.CND
.CND
.DAT
.DAT
.DAT
.DAT
To Next Page
