YASKAWA NX100 User Manual

3 Teaching
3.4 Modifying Steps
3-27
149235-1CD
RE-CSO-A031
3.4.1 Displaying the JOB CONTENT Window for Editing
 Currently Called Up Job
 Calling Up Other Jobs
Operation Explanation
1 Select {JOB} under the main
menu.
2 Select {JOB}. The JOB CONTENT window appears.
In any other than the teach mode, set the mode switch to “TEACH.”
Operation Explanation
1 Select {JOB} under the main
menu.
2 Select {SELECT JOB}. The JOB LIST window appears.
3 Select the job name to be
called.
NOTE
Main Menu
Short Cut
JOB LIST
TEST03
TEST
TEST3A
TEST01
TEST3A-!
TEST02
JOB EDIT
DISPLAY
UTILITY
91 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
