8 Parameter
8.3 Mode Operation Setting Parameters
8-20
149235-1CD
RE-CSO-A031
S2C297: SIGNAL NAME ALIAS FUNCTION
On the JOB CONTENT window, the name registered to the user input/output signal number can be
displayed as alias instead of the signal number itself.
With this function valid, the confirmation dialog box “Register by name (alias)?” is displayed when a
signal (IN#(), OT#(), IG#(), OG#(), IGH#(), OGH#()) is selected on the DETAIL EDIT window. Select
“YES” and the signal select window appears. Then select the target signal of number and press
[ENTER], and the registered name is displayed instead of the signal number. However, if the signal
number’s name is not yet registered, it is displayed by number as usual.
<Example> Registration of the name of user output OUT#0001 as “OUTPUT 1”
In the case of DOUT instruction:
S2C297=0 : DOUT OT#(1) ON
S2C297=1 : DOUT OT#(OUTPUT 1) ON
S2C297
Parameter Setting Value Valid/Invalid
0 Function invalid
1 Function valid
Select {IN/OUT} {UNIVERSAL INPUT/OUTPUT} to edit signal names on the window.
Up to 16 characters can be entered as a signal name. However, when this function is valid,
if the content below is entered, the error message shows and the name cannot be
registered.
• The name already registered
• Letters beginning with a number
• Letters including the signs below:
• ( , ) , [ , ] , = , < , > , space, comma
• Letters beginning with “alphabets representing variables” + “number”
<Example> B0..., I0..., BP1..., LEX2...
Alphabets representing variables: B, I, D, R, S, P, BP, EX, PX,
LB, LI LD, LR, LS, LP, LBP, LEX, LPX
When the name begins with “ ‘ ”, it is regarded as a comment and the same comment can
be registered for two or more signals. In this case, although this function is valid, the
number is displayed on the JOB CONTENT window instead of the name.
<Example> Registration of the name of user output OUT#0002 as “ ‘OUTPUT 2”
S2C297=0 : DOUT OT#(2) ON
S2C297=1 : DOUT OT#(2) ON
To Next Page
