4 Playback
4.5 Playback with Reserved Start
4-27
149235-1CD
RE-CSO-A031
4.5.2 Playback from Reserved Start
Start Operation
Operation Explanation
1 Set the mode switch to “PLAY.”
2 Press start button on the
station.
The job registered for the station starts up and the manipulator
performs one cycle operation.
• While the job is being executed, the start button lamp on the station lamps.
• If the workpiece must be prepared at the station, prepare it before pressing the start
button.
• If the start button of another station is pressed during execution of a job at one station, the
job on the station is reserved and prepares to start. Jobs are reserved and executed in
the order that the start buttons are pressed.
• When a job is reserved, the start button lamp on the station blinks.
• No station job is reserved when it is being executed even if its start button is pressed.
• To suspend a job being executed, perform the Hold operation.
Reservations are cancelled when the start button is pressed again during the job
reservation operation.
