YASKAWA NX100 User Manual

7 External Memory Devices
7.1 Memory Devices
7-3
149235-1CD
RE-CSO-A031
 Notes on handling Compact Flash
• Do not drop or bend exerting any shock or strong force to the Compact Flash.
• Keep away from water, oil, organic solvent, dust, and dirt.
• Do not use or keep the Compact Flash in places where strong static electricity or
electronic noise may occur.
• To protect the data, back up the data regularly on other media. Damages or loss of data
due to operation errors or accidents can be minimized.
*Compact Flash has a limited life span.
The life span differs depending on products or status of use. However, normal use of Compact Flash as
an external memory device for the NX100 does not adversely affect the Compact Flash. For details,
refer to instruction manuals for each medium.
Removing the CF or disconnecting the control power supply while writing data to the CF/
reading data from the CF may cause data corruption in the CF.
Please DO NOT remove the CF or disconnect the control power supply
while
• the remaining bytes indication is switching to the file list window after the data of the
external memory device is saved, loaded, or verified, and the hourglass icon disappears.
• the screen is switching to the file list window after the data of the external memory device
is deleted.
• the folder list is being updated after a folder is created to or deleted from a folder of the
external memory.
• the message "Under running auto backup" is being displayed.
• CMOS.BIN is being saved with the message "Saving system data. Don't turn the power
off" displayed.
• CMOS.BIN is being loaded with the message "Loading system data. Don't turn the power
off" displayed.
NOTE
247 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
