YASKAWA NX100 User Manual

9 Arc Welding Application
9.13 Power Source Condition File Initial Value
9-98
149235-1CD
RE-CSO-A031
POWER SOURCE NO.: 3
POWER SOURCE NAME:
MOTOWELD-E series 500A class
COMMENT: COMBINATION GAS AND WIRE
POWER SUPPLY: A (synergic)
SHIELDING GAS: MAG
WIRE DIA.: 1.2 mm
WIRE STICKOUT: 15 mm
WIRE ANTI-STICKING: 0.1 sec
ARC FAILURE STOP: 0.6 sec
POWER SOURCE NO.: 4
POWER SOURCE NAME:
MOTOWELD-E series 500A class
COMMENT: COMBINATION GAS AND WIRE
POWER SUPPLY: independent
SHIELDING GAS: MAG
WIRE DIA.: 1.2 mm
WIRE STICKOUT: 15 mm
WIRE ANTI-STICKING: 0.1 sec
ARC FAILURE STOP: 0.6 sec
CURRENT VOLTAGE CURRENT VOLTAGE
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
REF. (V) MEA. (A) REF. (V) MEA. (%) REF. (V) MEA. (A) REF. (V) MEA. (V)
0.00 30 0.00 50 0.00 30 0.00 12.0
1.35 77 7.20 99 1.35 77 2.25 17.5
2.70 124 7.50 100 2.70 124 4.50 23.0
10.80 406 7.80 101 10.80 406 6.75 28.5
12.15 453 14.00 150 12.15 453 9.00 34.0
13.50 500 0.00 0 13.50 500 11.25 39.5
0.00 0 0.00 0 0.00 0 13.50 45.0
0.00 0 0.00 0 0.00 0 0.00 0.0
441 of 493
