7 External Memory Devices
7.3 Operation Flow
7-37
149235-1CD
RE-CSO-A031
Loading All CMOS Data
Operation Explanation
1 Select {FD/PC CARD} under
the main menu.
2 Select {LOAD}. The following window appears.
3 Move the cursor to {BATCH
CMOS} and select.
4 Select “EXECUTE.” The confirmation dialog box appears.
5 Select “YES.” All CMOS data are loaded.
DATA UTILITY
EDIT
DISPLAY
Main Menu
ShortCut
FLOPPY DISK/Compact Flash
CF (LOAD) UN-USED MEMORY 55.32 MB
FOLDER
JOB
FILE/GENERAL DATA
BATCH USER MEMORY
PARAMETER
SYSTEM DATA
I/O DATA
BATCH CMOS
ALL CMOS AREA
57
0
0
0
0
0
0
0
YES
Load?
NO
