YASKAWA NX100 User Manual

9 Arc Welding Application
9.13 Power Source Condition File Initial Value
9-108
149235-1CD
RE-CSO-A031
POWER SOURCE NO.: 23
POWER SOURCE NAME:
MOTOWELD-S500
COMMENT: STC NO-CONTROL
POWER SUPPLY: A (synergic)
SHIELDING GAS: CO2
WIRE DIA.: 1.2mm
WIRE STICKOUT: 15mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 1.5sec
POWER SOURCE NO.: 24
POWER SOURCE NAME:
MOTOWELD-S500
COMMENT: STC NO-CONTROL
POWER SUPPLY: A (synergic)
SHIELDING GAS: MAG
WIRE DIA.: 1.2mm
WIRE STICKOUT: 15mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 1.5sec
CURRENT VOLTAGE CURRENT VOLTAGE
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(%)
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(%)
1.40 100 3.00 85 1.70 100 3.00 85
3.10 160 7.00 100 2.80 160 7.00 100
4.00 200 11.00 115 3.70 200 11.00 115
5.90 280 0.00 0 5.00 250 0.00 0
8.00 340 0.00 0 6.40 300 0.00 0
9.00 380 0.00 0 7.50 360 0.00 0
10.00 400 0.00 0 8.00 390 0.00 0
11.00 440 0.00 0 9.00 430 0.00 0
451 of 493
