YASKAWA NX100 User Manual

9 Arc Welding Application
9.13 Power Source Condition File Initial Value
9-107
149235-1CD
RE-CSO-A031
POWER SOURCE NO.: 21
POWER SOURCE NAME:
SHINKO ES350
COMMENT:
POWER SUPPLY: A (synergic)
SHIELDING GAS: CO2
WIRE DIA.: 1.2mm
WIRE STICKOUT: 15mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 0.6sec
POWER SOURCE NO.: 22
POWER SOURCE NAME:
DAIHEN CPV350
COMMENT:
POWER SUPPLY: A (synergic)
SHIELDING GAS: CO2
WIRE DIA.: 1.2mm
WIRE STICKOUT: 15mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 0.6sec
CURRENT VOLTAGE CURRENT VOLTAGE
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(%)
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(%)
2.80 100 4.80 88 1.40 50 5.00 75
3.90 150 7.00 100 2.80 100 7.50 100
5.80 200 9.20 112 4.30 150 10.00 125
7.60 250 0.00 0 5.70 200 0.00 0
8.90 300 0.00 0 7.80 250 0.00 0
0.00 0 0.00 0 9.50 300 0.00 0
0.00 0 0.00 0 12.60 350 0.00 0
0.00 0 0.00 0 0.00 0 0.00 0
