YASKAWA NX100 User Manual

9 Arc Welding Application
9.13 Power Source Condition File Initial Value
9-106
149235-1CD
RE-CSO-A031
POWER SOURCE NO.: 19
POWER SOURCE NAME:
MOTOWELD-S350-AJ2/3
COMMENT: STC CONTROL
POWER SUPPLY: independent
SHIELDING GAS: CO2
WIRE DIA.: 0.9mm
WIRE STICKOUT: 10mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 0.6sec
POWER SOURCE NO.: 20
POWER SOURCE NAME:
MOTOWELD-S350-AJ2/3
COMMENT: STC CONTROL
POWER SUPPLY: independent
SHIELDING GAS: MAG
WIRE DIA.: 0.9mm
WIRE STICKOUT: 10mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 0.6sec
CURRENT VOLTAGE CURRENT VOLTAGE
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(V)
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(V)
1.00 60 2.80 19.0 1.00 60 2.10 17.5
2.00 80 3.80 21.0 2.00 75 2.30 18.0
3.50 105 4.80 23.0 3.50 110 3.40 20.0
5.00 125 6.00 25.5 5.00 130 4.10 21.5
7.00 145 0.00 0.0 7.00 160 5.00 23.0
10.00 180 0.00 0.0 10.00 190 0.00 0.0
11.00 200 0.00 0.0 11.00 200 0.00 0.0
0.00 0 0.00 0.0 0.00 0 0.00 0.0
449 of 493
