YASKAWA NX100 User Manual

4 Playback
4.1 Preparation for Playback
4-4
149235-1CD
RE-CSO-A031
Calling from the MASTER JOB Window
Operation Explanation
1 Select {JOB} under the main
menu.
2 Select {MASTER JOB}. The MASTER JOB window appears.
3 Press [SELECT]. The selection dialog box appears.
4 Select {CALL MASTER JOB}. The master job is called, and the JOB CONTENT window (during
the teach mode), or the PLAYBACK window (during the play
mode) appears.
Main Menu
Short Cut
MASTER JOB
MASTER JOB : TEST01
JOB EDIT
DISPLAY
UTILITY
Main Menu Short Cut
MASTER JOB
MASTER JOB*******
JOB
EDIT DISPLAY UTILITY
CALL MASTER JOB
SETTING MASTER JOB
CANCEL MASTER JOB
156 of 493
