YASKAWA NX100 User Manual

7 External Memory Devices
7.2 Handling Data
7-6
149235-1CD
RE-CSO-A031
Data classification
File Name
(Saved Data)
Save Load
EDIT MAN EDIT MAN
 ALL CMOS AREA
ALCMSxx.HEX
XX
 BATCH CMOS
CMOSxx.HEX
X 
 BATCH USER MEMORY
JOBxx.HEX

 JOB
Single job JOBNAME.JBI

Related job (Job+Condition) JOBNAME.JBR

FILE/
GENERAL
DATA
Tool data TOOL.CND

Weaving data WEAV.CND

User coordinate data UFRAME.CND

Variable data VAR.DAT

Arc start condition data ARCSRT.CND

Arc end condition data ARCEND.CND

Welding condition auxiliary
data
ARCSUP.DAT

Power Source characteristic
data
WELDER.DAT

Power Source characteristic
definition data
WELDUDEF.DAT

Shock detection level data SHOCKLVL.CND

Motor gun pressure power
data
SPRESS.CND

Motor gun dry spot
pressure data
SPRESSCL.CND

Spot gun characteristic data SGUN.DAT

Spot gun condition auxiliary
data
SGUNSUP.DAT

Spot welding Power Source
characteristic data
SWELDER.DAT

Spot I/O allocation data SPOTIO.DAT

Spot welding condition data SPOTWELD.DAT

Short/Full open position data STROKE.DAT

