YASKAWA NX100 - Page 269

7 External Memory Devices
7.3 Operation Flow
7-25
149235-1CD
RE-CSO-A031
Saving All CMOS Data
Operation Explanation
1 Select {FD/PC CARD} under
the main menu.
2 Select {SAVE}. The following window appears.
3 Move the cursor to {BATCH
CMOS} and select.
4 Select “EXECUTE.” The confirmation dialog box appears.
5 Select “YES.” All CMOS data are saved.
DATA UTILITY
EDIT
DISPLAY
Main Menu ShortCut
FLOPPY DISK/Compact Flash
CF (SAVE) UN-USED MEMORY 55.91 MB
FOLDER
 JOB
 FILE/GENERAL DATA
 BATCH USER MEMORY
 PARAMETER
 SYSTEM DATA
 I/O DATA
 BATCH CMOS
 ALL CMOS AREA
57
0
0
0
0
0
0
0
YES
Save?
NO
269 of 493
