l2protocol-tunnel
To enable tunneling of Layer 2 protocols on an access port, IEEE 802.1Q tunnel port, or a port channel, use
the l2protocol-tunnel command in interface configuration mode on the switch stack or on a standalone
switch. Use the no form of this command to disable tunneling on the interface.
l2protocol-tunnel [drop-threshold | shutdown-threshold] [value] [cdp| stp | vtp ] [lldp] [point-to-point|
[pagp| lacp| udld]]
no l2protocol-tunnel [drop-threshold | shutdown-threshold] [value] [cdp| stp | vtp ] [lldp] [point-to-point|
[pagp| lacp| udld]]
Syntax Description
(Optional) Sets a drop threshold for the maximum rate of Layer 2 protocol packets
per second to be received before an interface drops packets.
drop-threshold
(Optional) Sets a shutdown threshold for the maximum rate of Layer 2 protocol packets
per second to be received before an interface is shut down.
shutdown-threshold
A threshold in packets per second to be received for encapsulation before the interface
shuts down, or the threshold before the interface drops packets. The range is 1 to 4096.
The default is no threshold.
value
(Optional) Enables tunneling of CDP, specifies a shutdown threshold for CDP, or
specifies a drop threshold for CDP.
cdp
(Optional) Enables tunneling of STP, specifies a shutdown threshold for STP, or
specifies a drop threshold for STP.
stp
(Optional) Enables tunneling or VTP, specifies a shutdown threshold for VTP, or
specifies a drop threshold for VTP.
vtp
(Optional) Enables tunneling of LLDP packets.lldp
(Optional) Enables point-to point tunneling of PAgP, LACP, and UDLD packets.point-to-point
(Optional) Enables point-to-point tunneling of PAgP, specifies a shutdown threshold
for PAgP, or specifies a drop threshold for PAgP.
pagp
(Optional) Enables point-to-point tunneling of LACP, specifies a shutdown threshold
for LACP, or specifis a drop threshold for LACP.
lacp
(Optional) Enables point-to-point tunneling of UDLD, specifies a shutdown threshold
for UDLD, or specifies a drop threshold for UDLD.
udld
Command Default
The default is that no Layer 2 protocol packets are tunneled.
The default is no shutdown threshold for the number of Layer 2 protocol packets.
Command Reference, Cisco IOS XE Everest 16.5.1a (Catalyst 3650 Switches)
1018
l2protocol-tunnel

Cisco Catalyst 3650 Series Specifications

General

RAM	4 GB
Flash Memory	4 GB
Ports	24 or 48 10/100/1000 Ethernet ports
Uplinks	4 x 1G SFP or 4 x 10G SFP+ (depending on model)
Stacking	Up to 9 switches with StackWise-160
Layer Support	Layer 2, Layer 3
Software	Cisco IOS Software
Power Supply	Internal power supply; optional redundant power supply available
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
