Cisco Catalyst 3650 Series

Valid SyntaxMedia Type
VTP v1 mode is enabled.
name vlan-name, media tr-net, state {suspend |
active}, said said-value, mtu mtu-size, bridge
bridge-number, stp type {ieee | ibm}, tb-vlan1
tb-vlan1-id, tb-vlan2 tb-vlan2-id
Token Ring-NET
VTP v2 mode is enabled.
name vlan-name, media tr-net, state {suspend |
active}, said said-value, mtu mtu-size, bridge
bridge-number, stp type {ieee | ibm | auto}, tb-vlan1
tb-vlan1-id, tb-vlan2 tb-vlan2-id
Token Ring bridge relay function (TrBRF)
The following table describes the rules for configuring VLANs:
Table 60: VLAN Configuration Rules
RuleConfiguration
Specify a parent VLAN ID of a TrBRF that already
exists in the database.
Specify a ring number. Do not leave this field blank.
Specify unique ring numbers when TrCRF VLANs
have the same parent VLAN ID. Only one backup
concentrator relay function (CRF) can be enabled.
VTP v2 mode is enabled, and you are configuring a
TrCRF VLAN media type.
Do not specify a backup CRF.VTP v2 mode is enabled, and you are configuring
VLANs other than TrCRF media type.
Specify a bridge number. Do not leave this field
blank.
VTP v2 mode is enabled, and you are configuring a
TrBRF VLAN media type.
No VLAN can have an STP type set to auto.
This rule applies to Ethernet, FDDI, FDDI-NET,
Token Ring, and Token Ring-NET VLANs.
VTP v1 mode is enabled.
Command Reference, Cisco IOS XE Everest 16.5.1a (Catalyst 3650 Switches)
1057
vlan
