• stp type—Defines the spanning-tree type for FDDI-NET, Token Ring-NET, or TrBRF VLANs. For
FDDI-NET VLANs, the default STP type is ieee. For Token Ring-NET VLANs, the default STP type
is ibm. For FDDI and Token Ring VLANs, the default is no type specified.
◦ ieee—IEEE Ethernet STP running source-route transparent (SRT) bridging.
◦ ibm—IBM STP running source-route bridging (SRB).
◦ auto—STP running a combination of source-route transparent bridging (IEEE) and source-route
bridging (IBM).
• tb-vlan1 tb-vlan1-id and tb-vlan2 tb-vlan2-id—Specifies the first and second VLAN to which this
VLAN is translationally bridged. Translational VLANs translate FDDI or Token Ring to Ethernet, for
example. The range is 0 to 1005. If no value is specified, 0 (no transitional bridging) is assumed.
Table 59: Valid Commands and Syntax for Different Media Types
Valid SyntaxMedia Type
name vlan-name, media ethernet, state {suspend |
active}, said said-value, mtu mtu-size, remote-span,
tb-vlan1 tb-vlan1-id, tb-vlan2 tb-vlan2-id
Ethernet
name vlan-name, media fddi, state {suspend |
active}, said said-value, mtu mtu-size, ring
ring-number, parent parent-vlan-id, tb-vlan1
tb-vlan1-id, tb-vlan2 tb-vlan2-id
FDDI
name vlan-name, media fd-net , state {suspend |
active}, said said-value, mtu mtu-size, bridge
bridge-number, stp type {ieee | ibm | auto}, tb-vlan1
tb-vlan1-id, tb-vlan2 tb-vlan2-id
If VTP v2 mode is disabled, do not set the stp type
to auto.
FDDI-NET
VTP v1 mode is enabled.
name vlan-name, media tokenring, state {suspend
| active}, said said-value, mtu mtu-size, ring
ring-number, parent parent-vlan-id, tb-vlan1
tb-vlan1-id, tb-vlan2 tb-vlan2-id
Token Ring
VTP v2 mode is enabled.
name vlan-name, media tokenring, state {suspend
| active}, said said-value, mtu mtu-size, ring
ring-number, parent parent-vlan-id, bridge type
{srb | srt}, are are-number, ste ste-number,
backupcrf {enable | disable}, tb-vlan1 tb-vlan1-id,
tb-vlan2 tb-vlan2-id
Token Ring concentrator relay function (TrCRF)
Command Reference, Cisco IOS XE Everest 16.5.1a (Catalyst 3650 Switches)
1056
vlan

Cisco Catalyst 3650 Series Specifications

General

RAM	4 GB
Flash Memory	4 GB
Ports	24 or 48 10/100/1000 Ethernet ports
Uplinks	4 x 1G SFP or 4 x 10G SFP+ (depending on model)
Stacking	Up to 9 switches with StackWise-160
Layer Support	Layer 2, Layer 3
Software	Cisco IOS Software
Power Supply	Internal power supply; optional redundant power supply available
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
