◦ tokenring—Token Ring media type if the VTP v2 mode is disabled, or TrCRF if the VTP Version
2 (v) mode is enabled.
◦ tr-net—Token Ring network entity title (NET) media type if the VTP v2 mode is disabled or
TrBRF media type if the VTP v2 mode is enabled.
See the table that follows for valid commands and syntax for different media types.
• mtu mtu-size—Specifies the maximum transmission unit (MTU) (packet size in bytes). The range is
576 to 18190. The default is 1500 bytes.
• name vlan-name—Names the VLAN with an ASCII string from 1 to 32 characters that must be unique
within the administrative domain. The default is VLANxxxx where xxxx represents four numeric digits
(including leading zeros) equal to the VLAN ID number.
• no—Negates a command or returns it to the default setting.
• parent parent-vlan-id—Specifies the parent VLAN of an existing FDDI, Token Ring, or TrCRF VLAN.
This parameter identifies the TrBRF to which a TrCRF belongs and is required when defining a TrCRF.
The range is 0 to 1005. The default parent VLAN ID is 0 (no parent VLAN) for FDDI and Token Ring
VLANs. For both Token Ring and TrCRF VLANs, the parent VLAN ID must already exist in the
database and be associated with a Token Ring-NET or TrBRF VLAN.
• private-vlan—Configures the VLAN as a private VLAN community, isolated, or primary VLAN or
configures the association between private VLAN primary and secondary VLANs. For more information,
see the private-vlan command.
• remote-span—Configures the VLAN as a Remote SPAN (RSPAN) VLAN. When the RSPAN feature
is added to an existing VLAN, the VLAN is first deleted and is then recreated with the RSPAN feature.
Any access ports are deactivated until the RSPAN feature is removed. If VTP is enabled, the new RSPAN
VLAN is propagated by VTP for VLAN IDs that are lower than 1024. Learning is disabled on the VLAN.
The RSPAN feature is supported only on switches running the LAN Base image.Note
• ring ring-number—Defines the logical ring for an FDDI, Token Ring, or TrCRF VLAN. The range is
1 to 4095. The default for Token Ring VLANs is 0. For FDDI VLANs, there is no default.
• said said-value—Specifies the security association identifier (SAID) as documented in IEEE 802.10.
The range is 1 to 4294967294, and the number must be unique within the administrative domain. The
default value is 100000 plus the VLAN ID number.
• shutdown—Shuts down VLAN switching on the VLAN. This command takes effect immediately. Other
commands take effect when you exit VLAN configuration mode.
• state—Specifies the VLAN state:
◦
active means the VLAN is operational (the default).
◦
suspend means the VLAN is suspended. Suspended VLANs do not pass packets.
• ste ste-number—Defines the maximum number of spanning-tree explorer (STE) hops. This keyword
applies only to TrCRF VLANs. The range is 0 to 13. The default is 7.
Command Reference, Cisco IOS XE Everest 16.5.1a (Catalyst 3650 Switches)
1055
vlan
