Kollmorgen AKD Basic User Manual

AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.3.1 AIN.CUTOFF
General Information
Type NV Parameter
Description
Sets the analog input low-pass filter cutoff
frequency.
Units Hz
Range 0 to 10,000 Hz
Default
Value
5,000 Hz
Data Type Float
Start Version M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 0 No 32 bit No M_01-03-00-000
Description
AIN.CUTOFF sets the break frequency in Hz for two cascaded single-pole low-pass filters on
the hardware command input. Since the two poles are cascaded at the same frequency, the -3
dB frequency is 0.64*AIN.CUTOFF in hertz and the 10% to 90% step response rise time is
0.53/AIN.CUTOFF in seconds.
Suggested operating values are as follows:
l Analog torque opmode: 5 kHz
l Analog velocity opmode: 2.5 kHz
l General purpose analog input high resolution: 500 Hz
Kollmorgen™ | March 30, 2012 124
