Kollmorgen AKD Basic

AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.6.4 CAP0.FILTER, CAP1.FILTER
General Information
Type R/W Parameter
Description
Sets the filter for the capture source
input.
Units N/A
Range 0 to 2
Default
Value
0
Data Type U8
See Also CAP0.PREFILTER, CAP1.PREFILTER
Start Version
End Version
M_01-00-00-000
M_01-03-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Object
Start
Version
Modbus
60 CAP0.FILTER
No 8 bit No
M_01-
03-00-
000
86 CAP1.FILTER
Description
These parameters are not functional in M_01-03-00-000. In future releases, you can use
DINx.FILTER to select a filter on the input channel.
Related Topics
DIN1.FILTER TO DIN7.FILTER
Kollmorgen™ | March 30, 2012 178
