6.35.4 WHEN.FB1MECHPOS
General Information
Type R/O
Description Records the value of FB1.MECHPOS when the when-condition is satisfied.
Units Position units
Range N/A
Default
Value
N/A
Data Type Integer
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1164 No 32 bit No M_01-05-11-000
Description
Records the value of FB1.MECHPOS when the when-condition is satisfied. The when-con-
dition is checked once per millisecond.
Related Topics
FB1.MECHPOS | WHEN.RESPOS | When
Kollmorgen™ | March 30, 2012 488
