Kollmorgen AKD Basic User Manual

AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.27 REC Parameters
This section describes the REC parameters.
6.27.1 REC.ACTIVE
General Information
Type R/O Parameter
Description
Indicates if data recording is in progress
(active).
Units N/A
Range 0 to 1
Default
Value
N/A
Data Type Integer
See Also REC.DONE , REC.OFF
Start Version M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 708 No 8 bit No M_01-03-00-000
Description
REC.ACTIVE indicates whether or not data recording is in progress. Recording is in progress if
the trigger was met and the recorder is recording all data.
413 Kollmorgen™ | March 30, 2012
