6.8.2 DIN.STATES
General Information
Type R/O Parameter
Description
Reads the digital input
states.
Units N/A
Range 0000000 to 1111111
Default
Value
N/A
Data Type String
See Also N/A
Start Version M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 118 No 8 bit No M_01-03-00-000
Description
DIN.STATES reads the states of the seven digital inputs. The leftmost bit represents digital
input 1 (DIN1) and the rightmost bit represents digital input 7 (DIN7).
