AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.16.2 FB2.MODE
General Information
Type R/W Parameter
Description
Sets the mode for the second feedback inputs, EEO connector (X9) and high
speed opto inputs (pins 9 and 10 on X7).
Units N/A
Range 0 to 2
Default
Value
0
Data Type Integer
See Also FB2.ENCRES , PL.FBSOURCE
Start Ver-
sion
M_01-03-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 986 No 16 bit No
Description
This parameter sets the feedback 2 input type as follows:
0 = Input A/B Signals
1 = Input Step and Direction Signals
2 = Input, up-down signals
Kollmorgenâ„¢ | March 30, 2012 292
