AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.11.8 DRV.DEC
General Information
Type NV Parameter
Description Sets the deceleration value for the velocity loop.
Units
Depends on UNIT.ACCROTARY or UNIT.ACCLINEAR
Rotary: rps/s, rpm/s, deg/s², (custom units)/s², rad/s²
Linear: counts/s², mm/s², µm/s², (custom units)/s²
Range
Rotary:
0.002 to 833,333.333 rps/s
0.112 to 50,000,000.000 rpm/s
0.009 to 300,000,000.000 deg/s²
0.155 to 4,166,666.752 (custom units)/s²
0.012 to 5,235,987.968 rad/s²
Linear:
16,000.000 to 3,579,139,408,000.000 counts/s²
0.031*MOTOR.PITCH to 833,333.333*MOTOR.PITCH mm/s²
30.994*MOTOR.PITCH to 833,333,333.333*MOTOR.PITCH µm/s²
0.155 to 4,166,666.667 (custom units)/s²
Default
Value
Rotary:
166.669 rps/s
10,000.000 rpm/s
60,000.000 deg/s²
833.333 (custom units)/s²
1,047.2 rad/s²
Linear:
715,840,000.000 counts/s²
166.71*MOTOR.PITCH4MOTOR.PITCH mm/s²
166,714.191*MOTOR.PITCHMOTOR.PITCH µm/s²
833.571 (custom units)/s²
Data Type Float
See Also
DRV.ACC , UNIT.ACCROTARY , UNIT.ACCLINEAR , DRV.O-
PMODE
Start Version M_01-00-00-000
Fieldbus Index/Subindex Object Start Version
EtherCAT COE and CAN-
open
3522h/0 M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 230 Yes 64 bit No M_01-03-00-000
Description
DRV.DEC sets the deceleration value for the velocity loop command (VL.CMDU ) and for the
analog
velocity command (AIN.VALUE ). The operation mode (DRV.OPMODE ) must be set to veloc-
ity mode for this command to function.
223 Kollmorgenâ„¢ | March 30, 2012
