6.10.3 DOUT8.MODE to DOUT11.MODE
General Information
Type NV Parameter
Description Sets the digital output mode.
Units N/A
Range 0 to 17
Default
Value
0
Data Type Integer
See Also DOUT1.PARAM AND DOUT2.PARAM
Start Version M_01-04-02-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus
196 DOUT1.MODE
No 8 bit No M_01-03-00-000
206 DOUT2.MODE
AKD BASIC Information
Range 8 to 11
Description
DOUTx.MODE sets the functionality of the digital outputs. The table below summarizes the
digital output modes; for detailed descriptions of each mode, see 1 Digital Inputs and Outputs.
DOUTx.MODE Description
0 User (default = 0)
8 Drive enabled
9 Reserved
10 Motor brake
11 Drive produced fault
