Kollmorgen AKD Basic User Manual

AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.4.5 AOUT.ISCALE
General Information
Type NV Parameter
Description
Sets the analog current scale fac-
tor.
Units A/V
Range 0.001 to 22.4 A/V
Default
Value
0.001 to 22.4 A/V
Data Type Float
See Also AOUT.VALUE
Start Version M_01-01-01-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 18 No 32 bit No M_01-03-00-000
Description
AOUT.ISCALE sets the analog current scale factor that scales the analog output
(AOUT.VALUE) for AOUT.MODE = 4 or 5. The value entered is the motor current per 10 V of
analog input or output. This value may be either higher or lower than 100%, but the actual
analog I/O will be limited by the application current limit (IL.LIMITN and IL.LIMITP ).
Kollmorgen™ | March 30, 2012 144
