AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.6.2 CAP0.EN, CAP1.EN
General Information
Type NV Parameter
Description
Enables or disables the related capture
engine.
Units N/A
Range 0 to 1
Default
Value
0
Data Type Boolean
See Also N/A
Start Version M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Object
Start
Version
Modbus
56 CAP0.EN
No 8 bit No
M_01-
03-00-
000
82 CAP1.EN
Description
This parameter enables or disables the related capture engine. After each successful capture
event, this parameter is reset to 0 and must be activated again for the next capture. Also note
that CAP0.PLFB, CAP1.PLFB is set to 0 when this parameter is set to 1.
0 = Disable
1 =Enable
Kollmorgen | March 30, 2012 174
