AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.26.8 PLS.WIDTH1 TO PLS.WIDTH8
General Information
Type R/W parameter
Description Programmable Limit Switch Width
Units Depends on UNIT.PROTARY or UNIT.PLINEAR
Range N/A
Default
Value
0
Data Type Float
See Also
PLS.EN, PLS.RESET, PLS.STATE, PLS.UNITS, PLS.MODE, PLS.P1 TO
PLS.P8, PLS.T1 TO PLS T8
Start Ver-
sion
M_01-02-03-000
AKD BASIC Information
Data Type Integer
Fieldbus Index/Subindex Object Start Version
EtherCAT COE and CAN-
open
34A1h/1 PLS.WIDTH1
34A1h/2 PLS.WIDTH2
34A1h/3 PLS.WIDTH3
34A1h/4 PLS.WIDTH4
34A1h/5 PLS.WIDTH5
34A1h/6 PLS.WIDTH6
34A1h/7 PLS.WIDTH7
34A1h/8 PLS.WIDTH8
M_01-02-03-000
Modbus
676 (64-
Bit)
PLS.WIDTH1
680 (64-
Bit)
PLS.WIDTH2
684 (64-
Bit)
PLS.WIDTH3
688 (64-
Bit)
PLS.WIDTH4
692 (64-
Bit)
PLS.WIDTH5
696 (64-
Bit)
PLS.WIDTH6
700 (64-
Bit)
PLS.WIDTH7
704 (64-
Bit)
PLS.WIDTH8
M_01-03-00-000
411 Kollmorgenâ„¢ | March 30, 2012
