AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.15.12 FB1.ORIGIN
General Information
Type NV Parameter
Description Adds to the initial feedback position.
Units
Depends on UNIT.ACCROTARY or UNIT.A-
CCLINEAR
Rotary: counts, rad, deg, custom units, 16-bit counts
Linear: counts, mm, µm, custom units, 16-bit counts
Range
Rotary:
0.000 to 5,123,372,000,000.000 counts
0.000 to 7,495.067 rad
0.000 to 429,436.096 deg
0.000 to 5,964.390 custom units
0.000 to 78,176,452.636 16-bit counts
Linear:
0.000 to 5,123,372,000,000.000 counts
0.000 to 1,192.878 mm
0.000 to 1,192,877.952 µm
0.000 to 5,964.390 custom units
0.000 to 78,176,452.636 counts16 Bit
Default
Value
0 counts
Data Type Float
See Also FB1.INITSIGNED
Start Version M_01-00-00-000
Fieldbus Index/Subindex Object Start Version
EtherCAT COE and CAN-
open
3656h/0 M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 294 Yes 64 bit No M_01-03-00-000
Description
FB1.ORIGIN is a value that is added to the feedback device position. Initial value and modulo
are determined from the number of bits of the feedback:
Initial position value = ( <feedback from device> + FB1.ORIGIN ) modulo <number of feedback
bits>
The number of feedback bits is set according to the feedback type. For memory feedbacks it is
the number of feedback bits; for none memory it is always single turn.
The drive internal process for the feedback initialization is as follows:
1. Reads the position feedback.
2. Adds the origin to the feedback.
3. Determines modulo from Step 2 by the actual feedback bits.
4. Sets the position feedback sign according to FB1.INITSIGNED.
Example
Kollmorgenâ„¢ | March 30, 2012 280
