AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.19.23 IL.VVFB
General Information
Type R/O Parameter
Description
Reads the measured voltage on the v-winding of the
motor.
Units V
Range –1200*VBusScale to +1200*VBusScale
Default
Value
N/A
Data Type Integer
See Also IL.VUFB
Start Version M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 478 No 16 bit Yes M_01-03-00-000
Description
The range for this parameter depends on whether the drive model is an MV/240 Vac or an
HV/480 Vac.
The VBusScale parameter sets the drive model:
MV/240 Vac: VBusScale = 1
HV/480 Vac: VBusScale = 2
VBusScale is used for multiple parameter ranges that are model dependent, such as IL.KP.
327 Kollmorgenâ„¢ | March 30, 2012
