AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.36.13 WS.VTHRESH
General Information
Type NV Parameter
Description Defines the maximum allowed velocity for Wake & Shake
Units
Depends on UNIT.VROTARY or UNIT.VLINEAR UNIT.A-
CCLINEAR
Rotary: rpm, rps, deg/s, custom units/s, rad/s
Linear: counts/s, mm/s, µm/s, custom units/s
Range
Rotary:
0.000 to 15,000.000 rpm
0.000 to 250.000 rps
0.000 to 90,000.000 degree/s
0.000 to 1,250.000 custom units/s
0.000 to 1,570.796 rad/s
Linear:
0.000 to 1,073,741,824,000.000 counts/s
0.000 to 8,000.000 mm/s
0.000 to 8,000,000.000 µm/s
0.000 to 1,250.000 custom units/s
Default
Value
100 rpm
Data Type U16
See Also N/A
Start Version M_01-01-00-101, M_01-02-00-000
Fieldbus Index/Subindex Object Start Version
EtherCAT COE and CAN-
open
3494h/4 M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 916 Yes low 32 bit word Yes M_01-03-00-000
Description
This parameter defines the maximum allowed velocity that occurs while commutation finding is
active. This supervision runs in real time, but only while wake and shake is active (WS.STATE
2 or greater, for Mode 0). If at any time while wake and shake is running a velocity higher than
this value is detected, fault F478 is generated. Setting WS.VTHRESH to zero disables this fea-
ture. For Mode 1, WS.VTHRESH is only used after the initial phase-finding.
Kollmorgenâ„¢ | March 30, 2012 504
