AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements

6.16.7 FB2.SOURCE

General Information

Type R/W Parameter

Description

Sets the source for the second feedback input. Choices are the EEO con-

nectors (X9) which are RS485 inputs, or the X7 connector’s high speed opto

inputs (pins 9 and 10).

Units N/A

Range 0 to 2

Default

Value

Data Type Integer

See Also FB2.ENCRES, FB2.MODE, PL.FBSOURCE

Start Ver-

sion

M_01-03-00-000

Fieldbus Index/Subindex Is 64 bit? Attributes Signed?

Modbus 988 No 16 bit No

Description

This parameter sets the secondary feedback source to be either the EEO connector (X9) or the

high speed opto inputs on the I/O Connector (X7) as follows:

0 = None

1 = Feedback Source X9 (EEO connector)

2 = Feedback Source X7 (High Speed Opto Inputs on the I/O Connector)
