AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.12.8 EGEAR.RATIO
General Information
Type TBD
Description
Sets the electronic gearing ratio (rev to rev) between the encoder shaft (master)
and the motor shaft (slave).
Units Motor revolutions / Encoder Revolution
Range -2,000 to 2,000
Default
Value
1
Data Type Float
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1074 No 32 bit No M_01-05-11-000
Description
Ratio must be set more recently than EGEAR.PULSESIN or EGEAR.PULSESOUT in order to
use EGEAR.RATIO to control electronic gearing.
Related Topics
EGEAR.ON | EGEAR.PULSESIN | EGEAR.PULSEOUT | FB2.SOURCE | FB2.ENCRES |
FB2.MODE
Kollmorgen™ | March 30, 2012 260
