AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.23.7 MOTOR.KE
General Information
Type NV Parameter
Description
Sets the motor back EMF con-
stant.
Units
Vpeak/krpm for Rotary Motors
Vpeak/m/s for Linear Motors
Range 0.0 to 100,000
Default
Value
0
Data Type Float
See Also N/A
Start Version M_01-03-06-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1216 No 32 bit No
Description
MOTOR.KEdefines the back EMF constant for the motor. The back EMF constant defines
how much voltage is generated at the motors coils. The relationship between MOTOR.KE and
speed is described by the following equation:
Coil Voltage = MOTOR.KE * VL.FB
Where:
VL.FB is in units of krpm for rotary motors and in units of m/s for linear motors
345 Kollmorgenâ„¢ | March 30, 2012
